LiFePO4 energy storage systems for distributors, installers & project partners Technical / RFQ: victor.gan@energy.pintopglobal.com
Products

Energy storage systems with clear technical data.

Start with the battery platform, then verify the inverter, load, backup requirement and destination-market documentation.

Residential ESS · LZH-512100

5.12 kWh Wall-mounted ESS

A compact low-voltage LiFePO4 battery platform for residential solar storage, backup and distributor portfolios.

Battery chemistry LiFePO4
Rated voltage 51.2 V
Rated capacity 100 Ah
Total energy 5.12 kWh
UN38.3 Test documentation available
Transport classification UN3480 / Class 9
High-capacity residential ESS · LZH-ESS-51.2-314-16.07kWh

16.07 kWh Floor-standing ESS

A high-capacity 51.2V LiFePO4 system for large homes, villas and light-commercial backup applications.

Battery chemistry LiFePO4
Rated voltage 51.2 V
Voltage range 43.2–58.4 V
Rated capacity 314 Ah
Total energy 16.07 kWh
Charge / discharge current 150 A
Charge / discharge power 7.68 kW
Communication CAN · RS232 · RS485
Recommended DoD 95%
Max. parallel quantity 16
Protection degree IP54
Cycle life 6,000–8,000 cycles
Transport documentation UN38.3 · SDS · UN3480 / Class 9
Warranty 5 years
Technical selection

What we need before confirming a system.

Application Backup / solar self-consumption / off-grid / light commercial
Inverter Brand + exact model + firmware / protocol requirement where relevant
System voltage Low-voltage / high-voltage architecture and battery voltage range
Power requirement Continuous load, peak load and required backup duration
PV system Installed or planned PV capacity
Market Destination country and required certification / documentation

Need a product recommendation?

Send the inverter model and application details. We will review the technical fit before quoting.

Send Project Details
